To simplify commissioning and to determine fuel/air ratio on multiple burner installations.
Supplied with measurement connections and choice of interchangeable orifices.
Solenoid safety valves for Air & Gas fast opening and fast closing type.
5. IGNITION TRANSFORMERS AND ELECTRODES
A range of ignition transformers and ignition electrodes are available to suit any burner application.
6. BURNER RELAYS
A complete range of flame detection systems is available including both U.V. scanners and flame rods.
7. PRESSURE SWITCH
Control of gas and air pressure negative pressure cut-out for gas and air. Indication for limitation valve.
8. UV SENSOR
Ultraviolet Flame Detectors detect the ultraviolet radiation emitted by combustion flames.
9. REGULATOR / RATIO REGULATOR
Regulator is typically used to pressure reducing and minimize the shock effect of
sudden downstream load changes.
Ratio Regulator is for maintaining constant gas/air ratios and zero regulator
operation for premix burners.
10. CONTROL MOTOR
A complete range available, simple – to fully modulating valves to suit all input control signals.
